Yanmar® 3-cylinder, liquid-cooled, diesel, 25 hp (18.4 kW) @ 3000 rpm. Stage V emissions compliance.

41 litres

0-15 km/h

SmartCool™ System. Electric with automatic or manual reversing for cleaning.

Engine-mounted hydrostatic transmission powering four hydraulic wheel motors providing dual-diagonal full-time all-wheel drive.

Volume: 810 litre

Grass Distributor: automatic electric-powered grass distributor for level filling

Full Collector Sensor: adjustable sensor detects when collector is full and disengages deck

Engineered Vent: air vent system is engineered to retain and pack clippings with minimal dust or debris discharge

Controls: separate hydraulic lift and hydraulic tip to dump. Rear door opens automatically when tipping.

Maximum Dump Height: 195 cm with 300 mm overhang

126 cm

2-11cm, infinitely variable, hydraulically-adjusted, remotely controlled from operator’s station

Formed and welded deck with front bull-nose bumper

46°

Standard

119 cm

Height: 207 cm ROPS up, 166 cm ROPS down

Overall Length: 291 cm

Overall Width: 143 cm

980 kg with cutting deck , 810 kg without cutting deck

2 years limited warranty. Refer to operator’s manual for further details.
